TYPE MG3

The Sealergy Seals Type MG3 is a mechanical seal with a non-pusher elastomeric bellows design, and it is a variant of the widely used MG series of seals. This seal is a common choice for a broad range of general-purpose and light chemical applications. It is often designed to be compatible with industry-standard models, such as the Burgmann MG3 or the CMG 3, making it a versatile and reliable choice. The MG3 seal's non-pusher elastomer bellows design allows it to compensate for minor shaft run-out and axial movements. This makes it a dependable choice for general industrial applications such as pumps, mixers, agitators, and compressors. The seal has a compact structure with a small working length, enabling it to fit into equipment with limited installation space. The elastomeric bellows also act as a secondary sealing element, providing a robust solution that is less prone to hang-up than other seal types. The MG3 seal is designed to operate under a variety of conditions. Depending on the material configuration, it can handle a range of fluids and is able to withstand temperatures from -40°C to 150°C and pressures up to 1.4 MPa. The MG3 is designed to be compatible with industry standards such as DIN24960, which simplifies procurement and replacement.

• Pressure: The working pressure is up to 0.8 MPa (around 8 bar).
• Non-Pusher.: Yes
• Unbalanced.: Yes
• It has a single-end structure.: Yes
• Bi-directional.: Yes
• Elastomer Bellow.: Yes
